UHF RFID Smartrac Dogbone Label 97×27mm | Impinj® M830
The ForNext 97×27mm UHF Smartrac Dogbone RFID label is engineered for applications that require maximum read range, high-speed inventory tracking and global performance consistency.
Built on the proven Smartrac Dogbone antenna platform, this next-generation version integrates the Impinj® M830 chip, delivering significantly enhanced sensitivity and reliability across global frequency bands.
This label is particularly suitable for automotive, logistics and industrial environments, where long-distance identification and fast bulk reading are critical. Typical use cases include inventory management, supply chain tracking and returnable transit items (RTIs).
With its optimised antenna design and advanced chip performance, the tag enables high-speed reading of large volumes, making it ideal for IoT-enabled operations and automated systems.
The label maintains a standard size of 97 × 27 mm with an antenna size of 94 × 24 mm, ensuring compatibility with existing converting and application processes.
The default face material is transparent PET, offering durability and consistent performance. Optional materials such as coated paper and PP synthetic paper are also available to meet different cost and application requirements.
Key Features
- Impinj® M830 chip for next-generation sensitivity and global performance
- Ultra-long read range — up to 20 m (FCC) / 15 m+ (ETSI) under optimal conditions
- Smartrac Dogbone antenna design for high efficiency and stability
- Optimised for high-speed bulk reading in logistics and industrial environments
- Ideal for automotive, supply chain and RTI tracking
- Supports IoT deployments requiring reliable large-scale identification
- Compatible with global UHF RFID systems
- Supports custom printing, EPC encoding and roll formats
Specifications
| Label Dimensions | 97 × 27 mm |
| Antenna Size | 94 × 24 mm |
| Chip | Impinj® M830 |
| Protocol | ISO/IEC 18000-6C; EPCglobal Class 1 Gen2v2 |
| Frequency | UHF 860–960 MHz (Global) |
| EPC Memory | 128 bits |
| User Memory | 0 bits |
| Read Range | Up to 20 m (FCC 902–928 MHz, fixed reader) Up to 15 m+ (ETSI 865–868 MHz, fixed reader)Actual read range may vary depending on reader power, antenna setup, environment and application conditions. |
| Face Material | Transparent PET (standard); coated paper / PP optional |
| Installation | Self-adhesive |
| Customisation | Printing, EPC encoding, serialisation, roll formats |
This Smartrac Dogbone RFID label with Impinj® M830 is designed for long-range, high-speed and large-scale RFID deployments, making it an excellent choice for modern logistics, industrial tracking and IoT applications.
