ForNext UHF LED RFID Label 44×18mm (Passive Light-Indicating Tag)
The ForNext 44×18mm UHF LED RFID label combines advanced EPC Gen2 wireless technology with an integrated visual indicator, enabling fast and accurate item-finding in busy warehouse, logistics, retail or industrial environments.
When the tag is activated by a compatible reader or handheld terminal, the embedded LED lights up and flashes, allowing users to instantly identify the correct item — even when items are stacked, mixed or stored in low-visibility locations.
Built on a passive UHF design, the label requires no battery, ensuring long-term reliability and lightweight performance. It uses an aluminium-etched antenna for stable RF behaviour and high read sensitivity across standard UHF operating bands (860–960 MHz).
With durable PET construction and strong adhesive backing, the tag is suitable for asset tracking, parts picking, tool management, apparel inventory and any scenario where fast visual confirmation is required.
Common search keywords: UHF LED RFID label, EPC Gen2 LED tag, item-finding RFID tag, flashing RFID tag, passive LED RFID sticker, UHF light-indicating label, Impinj-compatible LED tag, RFID picking system tag, warehouse LED RFID, inventory LED label.
Specifications
| Dimensions | 44 × 18 mm |
| Chip Type | KX2005X-BL (Compatibility with EPC Class1 Gen2 / ISO18000-6C) |
| Antenna | Aluminium Etched |
| Operating Frequency | 860–960 MHz |
| LED Function | Lights up/flashes when activated by reader command |
| EPC Memory | 240 bits |
| User Memory | 1312 bits |
| Password | 32-bit Access / 32-bit Kill |
| Read Range | Up to 10m on FCC, 5m on ETSI |
| TID | 96 bits (Read-Only) |
| Operating Mode | Passive (No battery required) |
| IC Endurance | 100,000 programming cycles |
| Data Retention | Up to 10 years |
| Material | PET + Adhesive |
| Operating Temperature | -25°C to +50°C |
| Storage Temperature | -25°C to +55°C |
| ESD Immunity | Up to 2kV (HBM) |
Key Features
- Built-in LED for fast item-finding and visual confirmation
- Fully passive UHF design — no battery required
- Compatible with standard EPC Gen2 readers
- High read sensitivity across 860–960 MHz
- Durable PET material suitable for warehouse and retail use
- Strong adhesive backing for easy installation on assets
- Ideal for inventory picking, order fulfilment, asset location and tool management
