UHF Magnetic On-Metal RFID Tag 105×30×7.5mm | NXP UCODE 8
Magnetic
The ForNext 105×30×7.5mm UHF magnetic on-metal RFID tag is engineered for applications that require reliable RFID identification on metal surfaces together with quick and convenient installation in industrial, warehouse and asset management environments.
Built with a durable ABS + PC housing, this industrial RFID tag is designed specifically for use on metal surfaces, where standard RFID labels often suffer from signal loss or unstable performance. Powered by the NXP UCODE 8 chip, it offers strong UHF performance for metal asset tracking, equipment identification, warehouse infrastructure and industrial logistics applications.
A key feature of this model is its magnetic attachment. Unlike adhesive or screw-mounted tags, this version can be quickly fixed onto suitable metal surfaces without drilling or permanent bonding. This makes it especially useful for applications where tags may need to be repositioned, replaced or deployed rapidly across movable metal assets, racks, containers, tools and industrial equipment.
With a size of 105 × 30 × 7.5 mm, the tag supports the global UHF frequency ranges of 902–928 MHz (US) and 865–868 MHz (EU). It uses the NXP UCODE 8 chip with EPC 128 bits and TID 96 bits memory, supporting dependable identification and stable data capture in demanding operating environments.
Designed for direct use on metal, the tag achieves up to 11 m (FCC fixed reader) and 10 m (ETSI fixed reader) read range. Under handheld readers, it supports up to 5.5 m (FCC) and 5 m (ETSI). Its tuned on-metal structure helps maintain dependable read performance in industrial environments where metallic interference would normally affect ordinary RFID labels.
Compliant with EPC Class 1 Gen 2 and ISO 18000-6C, this tag is suitable for a wide range of industrial identification and tracking tasks. With an operating temperature range of -25°C to +70°C, it is well suited to warehouse, logistics and manufacturing environments requiring durable, flexible and non-permanent RFID deployment on metal assets.
Key Features
- Optimised on-metal RFID design for reliable use on metal surfaces
- Magnetic attachment for quick, convenient and non-permanent installation
- NXP UCODE 8 chip for efficient UHF identification performance
- Durable ABS + PC housing for industrial and warehouse environments
- Long read range up to 11 m (FCC fixed) and 10 m (ETSI fixed)
- Compact 105 × 30 × 7.5 mm format for a wide range of metal assets
- Supports EPC Class 1 Gen 2 / ISO 18000-6C
- Suitable for tools, machinery, warehouse racks, containers and industrial equipment
- Ideal where repositionable or removable RFID installation is preferred
Specifications
| Model | FN-SM-105-M |
| Dimensions | 105 × 30 × 7.5 mm |
| Material | ABS + PC |
| Mounting Method | Magnetic attachment |
| Frequency | 902–928 MHz (US) / 865–868 MHz (EU) |
| Chip | NXP UCODE 8 |
| Protocol | EPC Class 1 Gen 2; ISO/IEC 18000-6C |
| Memory | EPC 128 bits; TID 96 bits |
| Applicable Surface | Metal surface |
| Read Range (Fixed) | 11 m (US 902–928 MHz); 10 m (EU 865–868 MHz) |
| Read Range (Handheld) | 5.5 m (US); 5 m (EU) |
| Operating Temperature | -25°C to +70°C |
| Weight | 30 g |
This magnetic on-metal RFID tag provides a practical solution for industrial users who need strong RFID performance on metal together with fast, flexible and removable installation across a variety of metal assets and equipment.
